60" / 72" Heavy-Duty Root Grapple – Fits John Deere Loader Quick Attach

OVERVIEW

Tackle tough land clearing, storm cleanup, and debris removal with this heavy-duty root grapple, specifically designed for John Deere tractor loaders. Available in 1524mm (60") and 1829mm (72") widths, this dual-cylinder attachment delivers exceptional clamping force and durability. Whether you are moving brush, logs, or large roots, the independent grapple arms ensure a secure grip on uneven loads, making it an essential tool for landscaping, forestry, and agricultural work.

SYSTEM HIGHLIGHTS

• Dual Independent Hydraulic Cylinders: Provide powerful, synchronized clamping force, allowing the arms to secure irregular loads with maximum stability.

• Open-Frame Design: Engineered to efficiently sift dirt and small debris from root systems and brush, leaving your topsoil behind.

• Heavy-Duty Steel Tines: Features reinforced steel tines with welded wear points to withstand high-impact use in rocky or compacted terrain.

• John Deere Quick Attach: Designed for a perfect, secure fit on John Deere 300, 400, and 500 series loaders with standard quick-attach hookups.

• Low-Maintenance Operation: Equipped with greaseable pivot points to ensure smooth movement and long-term reliability in harsh outdoor environments.

SPECIFICATIONS & DIMENSIONS

Feature	60" Model	72" Model
Working Width	1524mm (60")	1829mm (72")
Net Weight (approx.)	204kg (450lbs)	249kg (550lbs)
Clamping Mechanism	Dual Hydraulic Cylinders	Dual Hydraulic Cylinders
Tine Spacing	228–305mm (9–12")	228–305mm (9–12")
Mounting System	JD Quick Attach	JD Quick Attach
Material	Reinforced Industrial Steel	Reinforced Industrial Steel

IDEAL APPLICATIONS

Brush & Root Clearing - Storm Debris Cleanup - Land Grading & Site Prep - Forestry & Logging - Agricultural Property Maintenance
